Barton Size 3 45mm Plain Bearing Pulley Block Double Swivel Becket [N03231]

Barton Size 3 45mm Plain Bearing Pulley Block Double Swivel Becket [N03231]

Barton Marine
SKU:
MCS-111831
|
UPC:
5035088080984
$55.95
$57.38
(You save $1.43 )
(No reviews yet)
Width:
2.00 (in)
Height:
2.00 (in)
Depth:
5.00 (in)
Gift wrapping:
Options available
Current Stock:
Adding to cart… The item has been added
Description

Size 3 45mm Plain Bearing Pulley Block Double Swivel & Becket

The size 3 Barton plain bearing blocks have 45mm (1 3/4" sheave size 3 block range incorporates modern design with stainless steel frames and the latest advanced materials, using 30% fibre glass-filled nylon and Acetal sheaves to maximise their strength whilst keeping weight to a minimum. Suitable for use as mainsheet, vangs, lead blocks, or wherever a powerful and compact purchase system is required on dinghies, dayboats, and lightweight cruisers.

Suitable for up to 10mm (3/8") rope.

Specifications:

  • Weight: 143 g
  • Dimensions: 118 × 46 × 47 mm
  • Size: 3 (45MM)
  • Block Type: Swivel + Becket
  • No. of Sheaves: Double
  • Bearing Type: Plain
  • Sheave Size: 45mm x 13mm (1 3/4" x 35/64")
  • Max rope diameter: 10mm (3/8")
  • SWL: 400kg (881lbs)
  • Break load: 800kg (1763lbs)
  • Max rolling load (ball bearing blocks): 270kg (595lbs)


Quick Guide (pdf)
Warranty
Manufacturer's warranty: this item is covered by Barton Marine's warranty. Length and terms vary by product; see the manufacturer's website or ask us. To make a claim, contact Marine Craft | Supply at (252) 571-7789 or l.spicer@marinecraftsupply.com with your order number (and the serial number for electronics). We will help you file the claim with the manufacturer or our distributor. Warranty does not cover improper installation, misuse, or normal wear.
Additional Information
MPN:
N03231
