Actisense NMEA2000 Micro T Connector [A2K-T-MFF]

Actisense NMEA2000 Micro T Connector [A2K-T-MFF]

Actisense
SKU:
MCS-108174
|
UPC:
5060998710324
$30.00
(No reviews yet)
Width:
2.00 (in)
Height:
1.00 (in)
Depth:
2.00 (in)
Gift wrapping:
Options available
Current Stock:
Adding to cart… The item has been added
Description

NMEA2000 Micro T Connector

Quality-engineered connectors are shaped to allow easy and secure connections.

Two female and one male connector allow easy connection to Actisense NMEA lite cable assemblies, even when field-fit connectors are used, making it a unique T-piece.

The Actisense NMEA 2000 T-Piece is for use where a drop or ‘port’ is required from the NMEA 2000 backbone to connect another device.

The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.

Technical Specifications:

  • Rated Current - 4A
  • Rated Voltage - 60VDC
  • Male Contact - Brass, gold-plated
  • Female Contact - Phosphor bronze, gold plated
  • Contact Carrier - PA66 (30% Glass filled), black
  • Contact Polarization - Standard M12 -“A”- polarization
  • Mating Thread - M12
  • Screw Cap - Brass, nickel plated
  • O-Ring Seal - Rubber, black
  • Housing - PVC, black
  • Weight - 47g
  • Protection - IP67 (when mated)
  • Operating Temperature - -25°C to +70°C
  • Storage Temperature - -40°C to +85°C
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

  • Connection Gender: Male-Female
  • Data Interface: NMEA 2000
  • NMEA 2000 Connectors: Tee Connectors
  • Box Dimensions: 1"H x 2"W x 2"L WT: 0.15 lbs
  • UPC: 5060998710324

Owner's Manual (pdf)
Brochure (pdf)
Warranty
Manufacturer's warranty: this item is covered by Actisense's warranty. Length and terms vary by product; see the manufacturer's website or ask us. To make a claim, contact Marine Craft | Supply at (252) 571-7789 or l.spicer@marinecraftsupply.com with your order number (and the serial number for electronics). We will help you file the claim with the manufacturer or our distributor. Warranty does not cover improper installation, misuse, or normal wear.
Additional Information
MPN:
A2K-T-MFF
