Trident Marine 2" x 50 Coil Type A2 Fuel Fill Hose [327-2006]

Trident Marine 2" x 50 Coil Type A2 Fuel Fill Hose [327-2006]

Trident Marine
SKU:
MCS-98954
|
UPC:
704917009124
$829.95
$1,239.16
(You save $409.21 )
(No reviews yet)
Width:
31.00 (in)
Height:
8.00 (in)
Depth:
31.00 (in)
Gift wrapping:
Options available
Current Stock:
Adding to cart… The item has been added
Description

2" x 50' Coil Type A2 Fuel Fill Hose

Trident 2" ID A2 fuel fill hose for gasoline (including ethanol blends) and diesel (including bio diesel blends).

Features:

  • This hose is built with the best fuel, fire, and age-resistant formulation
  • Provides extraordinary resistance to aging, fire, heat, cold, and the ozone
  • Also, provides excellent bend-ability

Application:

  • Marine Fuel Hose for fill and vent plus diesel distribution
  • Approved, for all marine fuels including gasoline, alcohol blends, diesel and bio-diesel

Construction:

  • Tube & Cover: NBR / Neoprene
  • Reinforcement: High tenacity polyester 2 spiral, spring steel helix
  • Temperature Range: -20°F to 212°F (-20ºC to 100ºC)
  • Length: 50 ft. (15.24 m) Coil

Specifications:

  • Inner Diameter: (inch) 2" / (mm) 50.8
  • Outer Diameter: (inch) 2.48 / (mm) 63.5
  • Wall: (inch) 0.25 / (mm) 6.4
  • Working Pressure: (psi) 50 / (mpa) 0.345
  • Bend Radius: (inch) 7.0" / (mm) 178

*The #327 series exceeds ABYC H-24 & H-33, SAE J1527, ISO 7840, & USCG Type A2; and is NMMA Type Accepted, CE certified, and Lloyds Registry Type Approved

Specifications:

  • ID Diameter (inches): 2"
  • Length (Feet): 50'
  • Box Dimensions: 8"H x 31"W x 31"L WT: 56 lbs
  • UPC: 704917009124
Warranty
Manufacturer's warranty: this item is covered by Trident Marine's warranty. Length and terms vary by product; see the manufacturer's website or ask us. To make a claim, contact Marine Craft | Supply at (252) 571-7789 or l.spicer@marinecraftsupply.com with your order number (and the serial number for electronics). We will help you file the claim with the manufacturer or our distributor. Warranty does not cover improper installation, misuse, or normal wear.
Additional Information
MPN:
327-2006
