Schaefer Investment Cast Pad Eye - 3" OD Base [78-17]

Schaefer Investment Cast Pad Eye - 3" OD Base [78-17]

Schaefer Marine
SKU:
MCS-74764
|
UPC:
740507007866
$116.95
$134.10
(You save $17.15 )
(No reviews yet)
Width:
4.00 (in)
Height:
2.00 (in)
Depth:
5.00 (in)
Gift wrapping:
Options available
Current Stock:
Adding to cart… The item has been added
Description

Investment Cast Pad Eye - 3" OD Base

316 Stainless Steel includes delrin(tm) base. Order Backing Plate 97-54 separately.

Specifications:

  •  Eye Width 1-1/8" (29 mm)
  • Eye Height 7/8" (22 mm)
  • Eye Stock 1/2" (13 mm)
  • Length 3" (76 mm)
  • Width 3" (76 mm)
  • Fasteners (4), 3/8" FH (10 mm)
  • C/C A 1-1/8" (29 mm)
  • C/C B 1-11/16" (43 mm)
  • SWL 8500 lbs. (3800 kg)

Specifications:

  • Color: Stainless
  • Box Dimensions: 2"H x 4"W x 5"L WT: 0.75 lbs
  • UPC: 740507007866
Warranty
Manufacturer's warranty: this item is covered by Schaefer Marine's warranty. Length and terms vary by product; see the manufacturer's website or ask us. To make a claim, contact Marine Craft | Supply at (252) 571-7789 or l.spicer@marinecraftsupply.com with your order number (and the serial number for electronics). We will help you file the claim with the manufacturer or our distributor. Warranty does not cover improper installation, misuse, or normal wear.
Additional Information
MPN:
78-17
