Attwood Stainless Steel Thru-Hull Standard Straight Barbed - 1-1\/2" Inner Diameter [66551-3]

Attwood Stainless Steel Thru-Hull Standard Straight Barbed - 1-1/2" Inner Diameter [66551-3]

Attwood Marine
SKU:
MCS-98093
|
UPC:
022697665515
$55.95
$61.56
(You save $5.61 )
(No reviews yet)
Width:
5.00 (in)
Height:
3.00 (in)
Depth:
8.00 (in)
Gift wrapping:
Options available
Current Stock:
Adding to cart… The item has been added
Description

Stainless Steel Thru-Hull Standard Straight Barbed - 1-1/2" Inner Diameter

Polish your image with these beautiful, durable stainless steel fittings. Why specify plastic parts when these fittings will last the life of the boat?

Rugged Stainless Construction:

  • Cast from certified Enhanced 316 Stainless Steel alloy for strength and lifetime corrosion-resistance
  • All visible areas are polished to a mirror finish, then passivate each part for additional protection
  • Thick steel sidewalls withstand continual stress and hose flexing

Faster, Simpler Installation:

  • Each Thru-Hull is available with a new silicone gasket
  • A channel under the flange holds a bead of sealant, making it easier to apply a trouble-free seal
  • All models have wrench flats or an end notch to hold as a gripping surface; one installer can tighten all connections from inside the hull
  • The barbed tail ends provide plenty of room to hold multiple clamps

Stainless Steel Straight Thru-Hulls, Barbed

  • Standard Thread model has a full-length thread for thick hulls and easy tightening

Specifications:

  • Hose size: (inch) 1-1/2" inner diameter
  • Flange Diameter: (inch) 3"
  • Thread O.D. (outside diameter): (inch) 1-7/8"
  • Thread Length: (inch) 2-1/2"
  • Barb Length: (inch) 1-1/4"
  • Total Length: (inch) 4-1/8"
  • Install Hole Saw Size: (inch) 2"
  • Thread NPSM: (inch) 1-1/2"
  • Max Hull Thickness: (inch) 1-7/8"

*Stainless Steel Thru-Hull Connectors are designed for installation above the water line only

Specifications:

  • Hose Size: 1-1/2"
  • Material: Stainless Steel
  • Box Dimensions: 3"H x 5"W x 8"L WT: 1.55 lbs
  • UPC: 022697665515

Quick Guide (pdf)
Warranty
Manufacturer's warranty: this item is covered by Attwood Marine's warranty. Length and terms vary by product; see the manufacturer's website or ask us. To make a claim, contact Marine Craft | Supply at (252) 571-7789 or l.spicer@marinecraftsupply.com with your order number (and the serial number for electronics). We will help you file the claim with the manufacturer or our distributor. Warranty does not cover improper installation, misuse, or normal wear.
Additional Information
MPN:
66551-3
